Description
Details of ADSS Fiber Optic Cable
| SN | Item | Value |
| 1 | No. of fibers | 1-288 Core |
| 2 | Fiber | G652D or others |
| 3 | Armor | Aramid Yarn |
| 4 | Span | 50-200 m |
| 5 | Jacket | PE, Double Jacket |
| 6 | Packing | 4kms/roll |
The Tips of ADSS Fiber Optic Cable Installation:
1. The diameter of the traction wheel shall not be less than 500mm, and the groove shall be semicircular, its depth shall be greater than the outer diameter of the optic cable, and the wheel groove shall be made of rubber or nylon.
2. When installing an ADSS fiber optic cable, the pulley must be reliably grounded.
The straight-line distance from the tower to the cable laying equipment shall be greater than 4 times the height of the pulley suspension point to reduce the side pressure on the optic cable. Excessive tension shall not be used to pull the optic cable during cable laying, and the traction force shall not be greater than half of the initial tension borne by the optic cable. The traction speed of the optic cable is generally not greater than 20m/min.
3. The welding of self-supporting fiber optic cable shall be completed on the same day after the wiring of each coil is completed.
4. The tail cable reel and connecting reel shall be fixed on the tower at a position not less than 6m from the ground.
5. During ADSS cable installation, the optic cables located in the working area and between the static end connecting fittings shall be reliably grounded.
6. In order to ensure the connection quality and reduce the construction cost, the construction period of ADSS optic cable should be carried out in spring and autumn when there is less rain and snow. If construction has to be carried out in cold winter, temporary tents shall be erected and the temperature shall reach more than 0℃.
