GYXC8Y Fiber Optic Cable

in stock

The GYXC8Y Fiber Cable is a lightweight, all-dielectric figure-8 aerial cable designed with a central loose tube and a non-metallic FRP messenger for interference-free outdoor deployment.

Lightning Resistance: All-dielectric design with FRP messenger ensures safety in lightning-prone or high-voltage areas.
Compact & Lightweight: Central tube structure reduces cable diameter, making it easy to handle and install.
Cost-Efficient: Simplified non-metallic construction lowers both material and shipping costs for B2B projects.
Robust Protection: High-density PE jacket provides excellent UV resistance and environmental durability.

Description

Details of GYXC8Y Fiber Cable

SN	Item	Value
1	No. of fibers	1-12 Core
2	Fiber	G652D or others
3	Strength Member	FRP
4	Jacket	PE, Single Jacket
5	Packing	4kms/roll

The Tips of GYXC8Y Fiber Cable Installation:

Messenger Separation: Use specialized tools to separate the non-metallic FRP messenger from the main cable. Avoid scoring the FRP surface to maintain its full tensile strength.
Dielectric Hardware: Since GYXC8Y is an all-dielectric cable, use non-conductive tension clamps and suspension brackets to preserve the system’s anti-lightning properties.
Bending Radius Control: Adhere to a minimum bending radius of 20x the cable diameter. Over-bending can snap the stiff FRP member and damage the central tube fibers.
Safety in Power Areas: Ideal for high-voltage corridors; ensure the cable maintains safe clearance from power lines, though no grounding is required due to its non-metallic nature.
Weatherproofing: Apply high-quality waterproof sealant or heat-shrink tubing at all entry points to prevent moisture from entering the central loose tube.
