GYXC8S Fiber Optic Cable

in stock

The GYXC8S Fiber Cable is a compact figure-8 self-supporting aerial cable featuring a central loose tube design and a stranded steel messenger wire for efficient outdoor deployment.

Compact Design: Central tube structure offers a smaller diameter and lighter weight for easy handling.
Self-Supporting: Integrated steel messenger provides excellent tensile strength for long-span aerial use.
Crush Resistance: Steel wire reinforcement ensures robust mechanical protection in harsh environments.
Cost-Effective: Simplified construction reduces installation time and overall project expenses.

Description

Details of GYXC8S Fiber Cable

SN	Item	Value
1	No. of fibers	1-24 Core
2	Fiber	G652D or others
3	Strength Member	Stranded Steel Wires
4	Jacket	PE, Single Jacket
5	Packing	4kms/roll

The Tips of GYXC8S Fiber Cable Installation:

Precision Stripping: Use dedicated tube cutters to access the central loose tube. Avoid excessive force to protect the fibers within the compact structure.
Messenger Securing: Use heavy-duty dead-end grips or wedge clamps on the stranded steel wire to ensure stable tension for aerial spans.
Bending Discipline: Maintain a minimum bending radius of 20x the cable diameter during deployment to prevent signal attenuation or fiber damage.
Moisture Protection: Clean the water-blocking jelly thoroughly before splicing. Always use high-quality closure kits to seal the central tube ends.
Span Optimization: Adhere to the recommended maximum span ratings. For longer distances, ensure sag-tension calculations account for local wind and ice loads.
