Description
Details of GYDXTW Fiber Optic Cable
| SN | Item | Value |
| 1 | No. of fibers | 1-432 Core |
| 2 | Fiber | G652D or others |
| 3 | Strength Member | Parallel Steel Wire |
| 4 | Jacket | LSZH, Single Sheath |
| 5 | Packing | 4kms/roll |
The Tips of GYDXTW Fiber Optic Cable Installation:
- Ribbon Orientation: During splicing, ensure the fiber ribbons are correctly aligned by color code to prevent polarity errors in high-density links.
Tension Control: Pull using the parallel steel wire strength members; do not exceed the rated tension to avoid crushing the central loose tube.
Bending Radius: Maintain a minimum bending radius of 20x the cable diameter to protect the internal ribbon structure from micro-bending losses.
Duct Lubrication: Use specialized lubricants in ducts to reduce friction, especially for long-distance pulls of this armored ribbon cable.
Moisture Sealing: Use heat-shrinkable end caps immediately after cutting to protect the jelly-filled tube and steel tape from water ingress.
